RGB 8 Gang Switch Panel, Universal Circuit Control Relay System w/Momentary Toggle Pulsed Memory Function, Automatic Dimmable, 12-24V Light Switch Panel for Truck UTV Car Boat, IP65 Waterproof
Product details
| Management number | 221610966 | Release Date | 2026/05/03 | List Price | $36.00 | Model Number | 221610966 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Wide Vehicle Compatibility: The Porbi 8 Gang RGB Switch Panel works with all 12–24V vehicles including cars, trucks, ATVs, UTVs, SUVs, pickups, RVs, off-road vehicles, and boats. With a max power rating of 600W at 12V or 1200W at 24V, it easily controls your lighting, winch, or auxiliary equipment.
- RGB Backlight with Auto-Dimming: This switch panel features 7 vibrant backlight colors—red, yellow, green, blue, cyan, purple, and white. The built-in auto-dimming sensor automatically adjusts brightness based on ambient light—bright during the day, soft at night—to prevent eye strain and ensure visibility anytime.
- 3 Lighting Control Modes: This 8-gang panel offers TOGGLE (always on), MOMENTARY (press and hold), and PULSED (strobe) modes—perfect for controlling LED lights, horns, and other electronic accessories with flexible functionality.
- Reliable Safety Protection: Built with solid-state relays inside the control box and a resettable circuit breaker included for protection against reverse polarity, overcurrent, overvoltage, and overheating. IP65 waterproof housing ensures stable performance even in marine or outdoor environments.
- Easy Installation, 2 Mounting Options: The switch panel supports both flush mounting and adjustable angle mounting, allowing flexible installation to fit different vehicle dashboards or surfaces. Comes with two types of mounting brackets designed specifically for each installation method, along with a plug-and-play wiring harness for quick and neat setup.
- Durable Construction & Full Accessories Included: Made of rugged zinc alloy for superior heat resistance and longevity. The package includes: 1* switch panel, 1* circuit control box, 2* mounting brackets, 1* power harness, 1* circuit breaker, 80* DIY stickers, 10* zip ties, and 1* installation instructions. Backed by a 1+1 year Porbi warranty.
| Model | XR-OT044 |
|---|---|
| Wattage | 1200 watts |
| Terminal | Screw |
| Brand Name | Porbi |
| Unit Count | 1.0 Count |
| Item Weight | 5.07 Pounds |
| Part Number | XR-OT044 |
| Switch Type | Touch Switch |
| Circuit Type | 8-way |
| Contact Type | Normally Open |
| Manufacturer | Ruian Xiangrui Auto Electrical Appliance Co.,Ltd. |
| Material Type | Zinc Alloy |
| Mounting Type | Fix mount bracket & Flush mount |
| Connector Type | Quick Connect |
| Control Method | Touch |
| Current Rating | 60 Amps |
| Operation Mode | TOGGLE: Constantly on until switched off. MOMENTARY: Only active while pressing. PULSED: Creates strobe or flash effect |
| Item Dimensions | 4.52 x 2.59 x 0.57 inches |
| Number of Items | 1 |
| Contact Material | Aluminum |
| Operating Voltage | 12 Volts (DC) |
| Specification Met | FCC, UL |
| Included Components | Switch Panel、Circuit Control Box、Mounting Brackets、Power Harness, Connections |
| Number of Positions | 2 |
| Warranty Description | 1-year standard warranty + 1-year extended warranty with registration |
| Upper Temperature Rating | 221 Degrees Fahrenheit |
| International Protection Rating | IP65 |
| Global Trade Identification Number | 00199284922754 |
